Viotto RO Line

The main features of the Viotto double disc grinders, i.e. their stable and reliable design and their high precision, are the starting points for the creation of new model RO. These models have been completely redesigned from both technological and aesthetical standpoints. The model RO can show many important innovations:

Electrospindle technology for grinding wheels and dressing system. Designed entirely by Monzesi for the disc grinding applications to grant stable, precise, and highly reliable operations during processing.

All the axes are activated by brushless servo motors and precision ball screws.

New machine bed design which makes the machines more ergonomic.

Universal Dressing system redesigned in order to meet any requirement. We can use a fixed head with diamonds, a rotating spindle with electroplated wheel or with conventional abrasive.

Considerably simplified set-up of the machine through a new intuitive software and CNC controlled guideplates.

IndustryNET4

IndustryNet4 allows connection of your machine tool to the factory management system, to enable an efficient and seamless data exchange between the production line and the rest of the relevant factory departments.

All Monzesi machines are Industry 4.0 Ready.

Machine sizes and versions

ROTARY

THRUFEED

INTERPOLATED

 RO – Horizontal Line
Grinding Wheel Diameter 200 mm 350/450 mm 500/610 mm 760/915 mm
Spindle Power 2,2 + 2,2 kW 22 + 22 kW 37 + 37 kW 53 + 53 kW
Total Power 6 kW 85 kW 115 kW 165 kW
Overall Dimensions 1400x800x1200 mm 1750x2650x1700 mm 1850x2750x2200 mm 2200x2900x2500 mm
Weight 1600 kg 4500 kg 6000 kg 8000 kg

ROTARY

THRUFEED

INTERPOLATED

 RO – Horizontal Line
Grinding Wheel Diameter 200 mm 350/450 mm 500/610 mm 760/915 mm
Spindle Power 2,2 kW 22 kW 37 kW 53 kW
Total Power 4,5 kW 63 kW 78 kW 112 kW
Overall Dimensions 1400x800x1200 mm 1750x2650x1700 mm 1850x2750x2200 mm 2200x2900x2500 mm
Weight 1200 kg 3800 kg 5000 kg 6500 kg
